ALi Corporation

ALi Corporation (also known as Acer Laboratories Incorporated or Acer Labs Inc., and commonly known as ALi) is a major designer and manufacturer of embedded systems integrated circuits, and a former manufacturer of personal computer integrated circuits. It is based in Taiwan, and is a subsidiary of the Acer group.

The company was founded in 1987, its president is Teddy Lu. Part of ALi including the personal computer integrated circuits business was spun off as ULi Electronics Inc. in June 2003. ULi was acquired by Nvidia in 2006 for $52 million.

Products

Chipsets

80X86 Chipsets

Pentium and Socket 7 Chipsets

Slot 1 and Socket 370 Chipsets

Slot A and Socket A Chipsets

Socket 478 Chipsets

Socket 754/939/940 Chipsets

Southbridge Chips

VGA

M3141
M3143
M3145A AliCat - PCI SVGA card, 2 MB DRAM, external RAMDAC, no DDC support - most likely S3 Trio64V compatible
M3147V AliCat - PCI SVGA card, 2 MB (S3 Trio 64V compatible ?)
M3149 GUI Accelerator, 4 MB
M3151 GUI Accelerator, 8 MB

Video

M3307 MPEG-I Video Controller
M3309 MPEG-II Video w/ Software Audio Decoder
M3321 MPEG-II Audio/Video Decoder
M3325 Video/Audio Decoder
M3327 CPU
M3328 CPU

M3329 CPU (MIPS architecture)
- A1 (216 pin)
- B1 (216 pin)
- C E1 (128 pin)
  - PF (parallel)
  - SF (serial)
M3330 CPU

PC peripheral

M5105, M5107, M5109, M5113, M5119 SuperIO chip
M5123, M5125, M5132, M5135, M5140, M5145 SuperIO chip with KBC integrated
M5253, M5271, M5273, M5622, M5633 USB/FireWire PCI chipsets
M5281, M5283, M5619, M5621, M5636, M5637, M5642 PCI IDE
M5455 PCI AC'97 Sound
M5623 (USB 2.0), M5617 (USB 1.1) USB Scanner controller
M5632 USB Host-to-host
M5634, M5651 USB flash drive controller, probably clone of Phison chips
M5635 USB Cardreader
M5661, M5667, M7101, M7107, M7108 digital audio player controller
M5818 RTC chip, clone of Motorola MC146818

For embedded systems

M6117 is a highly integrated, low voltage, single-chip implementation of the Intel 386SX compatible microprocessor subsystem plus ALi M1217 chipset. The M6117 provides a static 386SX core derived from V.M. Technology VM386SX microprocessor, a DRAM controller, ISA bus logic, a real time clock, a keyboard controller, and a power management unit.

M6032 is an 8051-based Microcontroller with Dual Data Pointers, UART, 32 I/O lines, 3 Timers/Counters, 6 Interrupts/2 priority levels, 256 Bytes IDATA RAM, 256 Bytes on-chip XRAM.

M6759 is an 8051-based Microcontroller with Dual Data Pointers, UART, 32 I/O lines, 3 Timers/Counters, 6 Interrupts/2 priority levels, 64 KB Flash ROM, 256 Bytes IDATA RAM, 256 Bytes on-chip XRAM.
